Lifecycle:
Active (Mature)
Brand:
Welwyn
Series:
3810
Series | 3810 |
---|---|
Application | High value / voltage |
Mounting | Through hole |
Package | Axial |
Technology | Thick film |
Approval | None |
Example MPN | 3811-10GGI |
Termination Options | Pb-free |
Power | 0W |
---|---|
Rated Ambient Temperature | 20°C |
De-rate to 0W Ambient Temperature | - |
Max Ambient Temperature | 100°C |
LEV | 1kV |
Resistance min | 100MΩ |
Resistance max | 50GΩ |
Critical Resistance (where applying LEV dissipates Pr) | N/A: -Ω |
Tolerance | 1% |
TCR | 500ppm/°C |
Isolation Voltage of Insulation | Unspecified: ?V |
RoHS Compliant (if Pb-free) | Yes (see below) |
---|---|
RoHS Exemption | None |
China RoHS (if Pb-free) | Compliant |
REACH Status (if Pb-free) | See REACH statement pdf (below) |
CMRT Conflict Mineral Status | See CMRT Excel file (below) |
EMRT Extended Mineral Status | No EMRT available |
Termination Finish (if Pb-free) | e3 - Sn hot dipped |
Termination Finish (if Pb-bearing) | Not available |
How to Specify Pb-Free | All part numbers are Pb-free |
ECCN | EAR99 |
Packing | Tray |
---|---|
Quantity | Variable |
Nett Weight Each | 2.2g |
Reflow Process | Not applicable |
MSL | Not applicable |
Wave Process | Not applicable |
Shelf-life | None defined |
Launch Date | Pre-2000 |
---|---|
Lifecycle | Active (Mature) |
EOL Date / YTEOL Estimate | 5 years or more. (Reviewed May 24) |
Latest PCN Date | 27 Mar 24 |
Alternative Part Number | - |
